STEERING LINKAGE
NC NO. QTY PART NO. DESCRIPTION
047 002 15237801 TERMINAL ASSY-LEFT TIE-ROD
048 005 00179839 ·BOLT
049 005 00108580 ·WASHER
050 001 15228998 ·TIE-ROD HEAD-LEFT
052 001 09018309 ·PLATE-COVER
053 001 00444571 ·PLUG
054 001 09018310 ·BAFFLE RING
055 001 09105216 ·BEARING
056 001 09372594 ·DOUBLE-SCREW BOLT
057 004 15317485 SEAL RING
058 008 00271563 BOLT
059 008 09354243 NUT
060 002 15237800 TERMINAL ASSY-RIGHT TIE-ROD
061 005 00179839 ·BOLT
062 005 00108580 ·WASHER
063 001 15228999 ·TIE-ROD HEAD-RIGHT
065 001 09018309 ·PLATE-COVER
066 001 00444571 ·PLUG
067 001 09018310 ·BAFFLE RING
068 001 09105216 ·BEARING
069 001 09372594 ·DOUBLE-SCREW BOLT
A NOTE SERIAL NO. LOWER THAN T2281037 (DETROIT) AND
T351001 (CUMMINS) NEED TO USE 9384856 PIN, FROM ABOVE TWO
SERIAL NO. NEED TO USE 15237869 PIN.
2-2
ACCUMULATOR
NC NO. QTY PART NO. DESCRIPTION
A 001 15007340 ACCUMULATOR ASSY
001 001 15245482 ·TUBE ASSY
002 001 15021812 ·PISTON
003 002 15021811 ·SEAL
004 001 15007338 ·CAP-END
005 001 09190980 ·O RING
006 001 09220661 ·RING-BACKUP
007 001 15002608 ·SHIELD
008 001 06525035 ·RECHARGE VALVE
009 006 0022347l ·BOLT
010 001 00274253 ·O RING
011 006 15007339 ·WASHER-HARDENED
A NOTESUPER ACCUMULATOR ASSY IS 15002604
MULTIPLEX SAFETY VALVE
NC NO. QTY PART NO. DESCRIPTION
A 001 001 15247593 BODY-VALVE
002 001 15265078 ·PLUG
003 001 09038865 ·O RING
NOTE
A 15265696 VALVE SEAL UNIT.
