DIFFERENTIAL
NC NO. QTY PART NO. DESCRIPTION
001 001 00103393 COTTER PIN
002 001 09227330 NUT
003 001 15300938 YOKE ASSY
004 001 09232899 SLEEVE
005 001 15228172 DIFFERENTIAL 3.15:1
006 001 09227257 ·RETAINER
007 001 15244338 ·SEAL
008 008 00271560 ·BOLT
009 014 00179841 ·BOLT
010 014 00108580 ·LOCKWASHER
011 001 09227258 ·PINION CARRIER
012 ASR 09192605 ·SHIM
013 ASR 09192606 ·SHIM
014 ASR 09192607 ·SHIM
015 001 09226270 ·CARRIER
016 004 00274199 ··BOLT
017 004 09192618 ··BUSHING
018 ASR 09113457 ·LOCKWIRE
019 001 09226262 ·RETAINER PIN
020 001 00444944 ·PLUG
021 001 09141911 ·O RING
022 001 09423356 ·BEARING
023 002 00102615 ·SCREW
024 001 09228704 ·GEAR SET
025 001 07451617 ·BEARING
026 008 00103331 ·LOCKWASHER
TABLE NO. B10458 R04
2-1
8-01-346 R04
NC NO. QTY PART NO. DESCRIPTION
027 004 09063982 ·WASHER
028 004 09005259 ·PINION
029 001 00219305 ·PLUG-PIPE
030 001 09005267 ·SPIDER
031 002 09247386 ·SIDE GEAR
032 001 09394277 ·CASE ASSY
033 001 N.S.S ··CASE
034 012 00454754 ··NUT
035 001 N.S.S ··CASE
036 012 09005582 ··BOLT
037 002 09192619 ·ADJUSTER
038 004 09219084 ·PIN
039 002 00456470 ·CONE-BEARING
040 002 00456471 ·CUP-BEARING
041 012 09419496 ·NUT
042 012 00223771 ·NUT
043 004 09170517 ·BOLT
044 002 09214341 ·LOCK
045 004 09114897 ·SCREW
046 002 09005581 ·WSHAER
A 047 ASR 15234244 ·SEAL (A:NOT SHOW IN GRAPH)
048 022 09419493 ·LOCKNUT
049 016 09250715 ·WASHER-HARDENED
050 006 15249834 ·SPACING RING-HARDENED
051 001 09219080 ·WASHER
052 002 00139230 ·SCREW
